Dhupar Brothers Trading Pvt Ltd

AU RCCB 25A DP 240V Adi 100mA AURAD202510

AU RCCB 25A DP 240V Adi 100mA AURAD202510

Regular price Rs. 2,394.00
Regular price Sale price Rs. 2,394.00
Sale Sold out

Technical Specification

Operating Temperature Range -25?C to +60?C
Electrical life (Operating Cylces) 10,000
Tightening Torque 4Nm
Termination capacity 35 Sq. mm (Rigid)25 Sq. mm (Flexible)
Mechanical Life (Operating Cycles) 20,000
No. of Poles DP
Rated Insulation Voltage Ui (V) 500V
Rated Frequency 50Hz
Rated Residual Making & Breaking capacity 1kA
Rated Impulse Voltage 6kV
Rated Conditional SC Current 10kA
Current Rating 40A
Rated operational voltage (Ue) 240V
Conformance to Standards IEC 61008-1
Sensitivity 100mA
Length(mm) 77.5
Height(mm) 100.6
Breadth(mm) 35
