Dhupar Brothers Trading Pvt Ltd

EXORA MCB 0.5A FP 415V AC 10kA C Curve BB40E50C

EXORA MCB 0.5A FP 415V AC 10kA C Curve BB40E50C

Regular price Rs. 1,641.50
Regular price Rs. 2,345.00 Sale price Rs. 1,641.50
Sale Sold out

Out of stock

Technical Specification

Operating Temperature Range -25?C to +70? C
Electrical life (Operating Cylces) 20000
Tightening Torque 4Nm
Termination capacity 35 Sq. mm (Rigid)25 Sq. mm (Flexible)
Mechanical Life (Operating Cycles) 100000
No. of Poles FP
Conformance to standards IS/IEC 60898-1IEC 60947-2
Rated Insulation Voltage Ui (V) 500V
Rated Frequency 50Hz/60Hz
Rated Short-circuit Breaking Capacity 10kA as per IS/IEC 60898-1 15kA as per IEC 60947-2
Rated Impulse Voltage 4kV
Current Rating 1A
Rated Operational voltage (Ue) 415V
Conformance to Standards IS/IEC 60898-1IEC 60947-2
Tripping Characteristic C Curve
Length(mm) 74.5
Height(mm) 87.3
Breadth(mm) 70
