Dhupar Brothers Trading Pvt Ltd
EXORA MCB 16A DP 240V AC 10kA C Curve BB20160C
EXORA MCB 16A DP 240V AC 10kA C Curve BB20160C
Regular price
Rs. 637.00
Regular price
Rs. 910.00
Sale price
Rs. 637.00
Unit price
/
per
In stock
Couldn't load pickup availability
Technical Specification
| Operating Temperature Range | -25?C to +70? C |
| Electrical life (Operating Cylces) | 20000 |
| Tightening Torque | 4Nm |
| Termination capacity | 35 Sq. mm (Rigid)25 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 100000 |
| No. of Poles | DP |
| Conformance to standards | IS/IEC 60898-1IEC 60947-2 |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Frequency | 50Hz/60Hz |
| Rated Short-circuit Breaking Capacity | 10kA as per IS/IEC 60898-1 15kA as per IEC 60947-2 |
| Rated Impulse Voltage | 4kV |
| Current Rating | 20A |
| Rated Operational voltage (Ue) | 240V |
| Conformance to Standards | IS/IEC 60898-1IEC 60947-2 |
| Tripping Characteristic | C Curve |
| Length(mm) | 74.5 |
| Height(mm) | 87.3 |
| Breadth(mm) | 35 |
