EXORA MCB 50A DP 250V DC 6kA C Curve BB2050DC
EXORA MCB 50A DP 250V DC 6kA C Curve BB2050DC
Regular price
Rs. 736.00
Regular price
Sale price
Rs. 736.00
Unit price
/
per
Couldn't load pickup availability
Technical Specification
| Operating Temperature Range | -25?C to +70?C |
| Electrical life (Operating Cylces) | 3000 |
| Tightening Torque | 4Nm |
| Termination capacity | 35 Sq. mm (Rigid)25 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 100000 |
| No. of Poles | DP |
| Conformance to standards | IEC 60947-2 |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Short-circuit Breaking Capacity | 6kA |
| Rated Impulse Voltage | 4kV |
| Current Rating | 63A |
| Rated Operational voltage (Ue) | 250V |
| Conformance to Standards | IEC 60947-2 |
| Tripping Characteristic | C Curve |
| Length(mm) | 74.5 |
| Height(mm) | 87.3 |
| Breadth(mm) | 35 |
