Dhupar Brothers Trading Pvt Ltd
Tripper MCB 20A SP 240V AC 6kA B Curve BA10200B
Tripper MCB 20A SP 240V AC 6kA B Curve BA10200B
Regular price
Rs. 103.00
Regular price
Sale price
Rs. 103.00
Unit price
/
per
Couldn't load pickup availability
Technical Specification
| Operating Temperature Range | -25?C to +70?C |
| Electrical life (Operating Cylces) | 10000 |
| Tightening Torque | 4Nm |
| Termination capacity | 35 Sq. mm (Rigid)25 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 100000 |
| No. of Poles | SP |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Frequency | 50Hz/60Hz |
| Rated Short-circuit Breaking Capacity | 6kA |
| Rated Impulse Voltage | 4kV |
| Current Rating | 25A |
| Rated operational voltage (Ue) | 240V |
| Conformance to Standards | IS/IEC 60898-1 |
| Tripping Characteristic | B Curve |
| Length(mm) | 74.5 |
| Height(mm) | 87.3 |
| Breadth(mm) | 17.5 |
